Run a Logos Blockchain node on the public testnet from the CLI

Start a node and verify runtime and consensus signals.​

Version

This document is accurate for Testnet v0.3.

With this tutorial, you will install the Logos Blockchain node, connect to the public testnet, and verify that your node is running. The Logos Blockchain is the blockchain component of the Logos technology stack, providing a privacy-preserving and censorship-resistant framework for decentralised applications. This procedure is for node operators setting up a node for the first time.

Prerequisites

  • CPU: 2 Cores, 2Ghz. Modern multi-core processor. Must have ADX instruction support (on x86_64), such as Intel Broadwell or later, or any AMD Zen. On virtual machines, configure the hypervisor to pass through host CPU features. Generic CPU models such as kvm64 and qemu64 hide ADX and cause the blockchain module to crash with signal 4.

    • Check whether your CPU has ADX support by running:
    # Linux
    grep -o adx /proc/cpuinfo | head -1

    # macOS
    sysctl -a | grep -i adx

  • A supported OS:

    • Linux x86_64
    • macOS aarch64 (recent versions)
    • Raspberry Pi 5 with Raspberry Pi OS

  • glibc version 2.39 or later (Linux only)

  • FUSE, required by the logosctl AppImage (Linux only). On Debian/Ubuntu: sudo apt install fuse libfuse2t64. Without it, logosctl fails with No suitable fusermount binary found on the $PATH.

  • Memory (RAM): Minimal (1 Gb).

  • Storage:

    • For joining the testnet or a short-lived node: SSD with 1-2 GB free.
    • Expected for a long-lived mainnet node: SSD with 100+ GB free with ability to expand storage on demand.

  • Network: Relatively reliable network connection. 1Mbps of free bandwidth.

  • logosctl installed.

    • Install it by running curl -fsSL https://raw.githubusercontent.com/logos-co/logos-docs/main/resources/scripts/install-logosctl.sh | sudo sh

What to expect​

  • You can install the node binary, generate a configuration, and join the public testnet.
  • You can verify that your node is syncing and connected to peers using the local API.
  • You can mine test tokens and automatically participate in the consensus lottery once your stake matures.

Step 1: Load the Logos Blockchain module​

Download the Logos Blockchain module from the catalogue, then load it in logosctl.

  1. Start logosctl from the directory where you want the node's files to live, for example your home directory:

    cd ~
    logosctl daemon start
    • The blockchain module writes user_config.yaml, keystore.yaml, the state/ directory and the node log files to the daemon's working directory, and resolves relative config paths against it.

  2. In a new terminal window with the same user, refresh the official module catalogue. Run this even if the daemon was already running, because it does not see packages published after it last refreshed:

    logosctl catalog refresh

  3. Install the Logos Blockchain module package version 0.3.2:

    logosctl package install blockchain_module \
    --version 0.3.2 \
    --yes
    note

    Individual module package versions are pinned independently and do not necessarily match the testnet version number.

  4. Load the Logos Blockchain module:

    logosctl module load blockchain_module
    • A module load sent before the daemon is ready fails with an RPC or missing client config error. If that happens, check logosctl status again and retry.

Step 2: Configure and start the node​

The generate_user_config subcommand generates a user configuration that includes per-node settings such as keys, ports, and peer addresses, along with fresh cryptographic keys and an auto-detected public IP.

info

Make sure to use the current bootstrap peer addresses in the Logos Blockchain Node release notes for your selected release.

  1. Generate your user_config.yaml and keystore.yaml files by running generate_user_config with the bootstrap peer addresses. The daemon writes both files to the directory you ran logosctl daemon start from, so run the commands in this step from that directory. The examples assume it is $HOME. For example, for release 0.3.2:

    logosctl call blockchain_module generate_user_config '{
        "initial_peers": [
            "/ip4/65.109.51.37/udp/3000/quic-v1/p2p/12D3KooWFrouXfmrR4nsLMtE7wu15DoMJ6VtoUtHinREZCvbWHar",
            "/ip4/65.109.51.37/udp/3001/quic-v1/p2p/12D3KooWJRGau8M1rjT7R5e4YYsgdFhsMX35nRDtMwCDjxQkXAHz",
            "/ip4/65.109.51.37/udp/3002/quic-v1/p2p/12D3KooWQXJavMDTRscjauFSgVAB1VLB6Rzpy2uY5SU9Tk7927tb",
            "/ip4/65.109.51.37/udp/50001/quic-v1/p2p/12D3KooWSQc7CcGtvWDPF1yCbBthFnQjprfCVHmfmNDUrSmqQsU1"
        ]
    }'

    chmod 600 user_config.yaml keystore.yaml
    info

    user_config.yaml contains node-local wallet and key-management configuration. Keep it private, restrict file permissions, and do not publish it. Generate a fresh file for each node.

    • Important fields in user_config.yaml include:
    FieldPurposeGuidance
    network.backend.initial_peersBootstrap peersUse the current network document
    network.backend.swarm.portPublic UDP P2P portKeep aligned with firewall/NAT, normally 3000
    api.backend.listen_addressLocal API bindKeep private, normally 127.0.0.1:8080. Edit the file if you want to change the port
    state.base_folderState directoryUse a persistent local path
    logger filtersLog verbosityUse INFO for unattended operation

  2. Start the node:

    logosctl call blockchain_module start "$HOME/user_config.yaml" ""
    • A relative path is resolved against the daemon's working directory. If you started the daemon elsewhere, pass the absolute path to user_config.yaml.
    • The second argument is intentionally an empty string; the blockchain module no longer requires a downloaded deployment.yaml file.
    info

    The Logos Blockchain node does not currently support dynamic wallet key management. To add new keys you must manually edit user_config.yaml and restart the node. If the node is restarted while bootstrapping, it does not save sync progress and restarts from the beginning.

Step 3: Verify that your node is running and connected to peers​

Wait for your node to finish syncing and reach Online mode before mining. Pipe the get_cryptarchia_info command through jq . to format JSON output.

  1. Check the consensus state. The logosctl call and the node's HTTP endpoint return the same data in slightly different shapes.

    logosctl call blockchain_module get_cryptarchia_info | jq -r .result.value | jq .

    Example response (the logosctl call returns a flat object with a mode field):

    {
      "lib": "3d0c...4e6d",
      "lib_slot": 0,
      "tip": "f44d...e2f5",
      "slot": 70899,
      "height": 120,
      "mode": "Bootstrapping"
    }

    Alternatively, send a request directly to your node port:

    curl -s http://localhost:8080/cryptarchia/info | jq .

    Example response (the HTTP endpoint nests the fields under cryptarchia_info, names the status field state, and adds a top-level phase):

    {
      "cryptarchia_info": {
        "lib": "3d0c...4e6d",
        "lib_slot": 0,
        "tip": "f44d...e2f5",
        "slot": 70899,
        "height": 120,
        "state": "Bootstrapping"
      },
      "phase": "ProlongedBootstrapPeriod"
    }
    • The status field (mode from the logosctl call, state from the HTTP endpoint) starts as Bootstrapping while syncing and transitions to Online once caught up.
    • Confirm slot and height are increasing. height counts confirmed blocks; slot counts elapsed time intervals, with a new block expected roughly every 10 seconds.

  2. Check peer connectivity:

    curl -s http://localhost:8080/network/info | jq .

    Example response:

    {
      "listen_addresses": ["/ip4/127.0.0.1/udp/3001/quic-v1"],
      "peer_id": "12D3...fuS2",
      "connected_peers": ["12D3...Mxu1", "12D3...sbD3"],
      "discovered_peers": ["12D3...Mxu1", "12D3...sbD3"],
      "n_peers": 16,
      "n_connections": 19,
      "n_discovered_peers": 18,
      "n_pending_connections": 0
    }
    • Confirm n_peers is greater than 0.

  3. After 30–60 seconds, run the get_cryptarchia_info command again and confirm slot and height have increased.

  4. Wait until mode transitions to Online before continuing. Bootstrapping should take approximately 1 hour.

Step 4: Mine tokens to fund your node​

A synced node validates the chain but does not propose blocks unless its wallet holds notes, which can be obtained by mining. The user_config.yaml generated in Step 2 includes a pow section that automatically claims mined rewards into your node's PoWClaim key.

warning

Do not call pow_status or pow_claimable_rewards before the node is Online. While the node is bootstrapping these calls never return, and every later logosctl call blockchain_module command fails with RPC call failed until you restart the daemon with logosctl daemon stop.

  1. After your node reaches Online mode, start mining:

    logosctl call blockchain_module pow_start_mining
    • Mining is off by default and does not persist across restarts. Run pow_start_mining again after every restart.
    • Auto-claim starts automatically. You do not need to call pow_start_auto_claim.

  2. Check the mining and auto-claim status:

    logosctl call blockchain_module pow_status | jq -r .result.value | jq .
    • is_mining is true, and the balance of the auto-claim target grows as auto-claim collects rewards. The target's public_key is your PoWClaim key.

  3. Check the balance of your PoWClaim key. Replace <your-powclaim-key> with the public_key from the previous step:

    curl -s http://localhost:8080/wallet/<your-powclaim-key>/balance | jq .

  4. Mining uses CPU for as long as it runs. Once you have enough funds, stop it:

    logosctl call blockchain_module pow_stop_mining
info

Your tokens become eligible for consensus after 3.5 hours. Confirm that your node is participating by checking that mode remains Online and height continues to increase.

Block proposal is probabilistic. Your node will not propose on every slot; participation depends on your stake relative to total active stake in the network.

Step 5: Claim leader rewards​

Each block your node proposes mints a leader-reward voucher. On a CLI node, vouchers are not credited automatically; you claim them to turn them into spendable balance.

Run this step only once your node reports mode: Online (Step 3) and your stake has matured. The chain-leader service is not available while the node is still Bootstrapping, and leader_claim fails there with an unrelated error rather than the response shown below.

  1. Check what is currently claimable. The value field is a JSON string, so extract and re-parse it:

    logosctl call blockchain_module wallet_get_claimable_vouchers | jq -r .result.value | jq .

    Example response:

    {
      "tip": "e5f28df8...9153e",
      "vouchers": []
    }

  2. Claim an available voucher:

    logosctl call blockchain_module leader_claim

    On success the call returns success: true with the claim transaction hash in value. When there is nothing to claim, it returns:

    {
      "method": "leader_claim",
      "module": "blockchain_module",
      "result": {
        "error": "Failed to claim leader rewards: Chain leader service error: Wallet API error: No claimable voucher found",
        "success": false,
        "value": null
      },
      "status": "ok"
    }
info

leader_claim claims one voucher per call. To drain several, check wallet_get_claimable_vouchers and call leader_claim once per listed voucher, pausing a few seconds between calls to avoid a burst of failures.

A voucher becomes claimable only once it is provable against the current tip, so a claim can be a temporary no-op (No claimable voucher found) shortly after a block is led; retry on the next check. leader_claim currently returns only the transaction hash, not the voucher it consumed or the fee paid.

Distinguish the two failure shapes. A reply with "status": "ok" and result.success: false means the node answered and had nothing to claim. A reply with "status": "error" and no result object means the call never reached the chain-leader service: either it timed out (call to 'blockchain_module.leader_claim' timed out after 20000ms) or the service is not running yet (Failed to establish connection to chain-leader-service). Both of the latter mean the node is not Online yet; re-check Step 3 rather than retrying the claim.

Troubleshooting the Logos Blockchain node​

logosctl call fails with RPC call failed?​

An error such as:

{"code":"RPC_FAILED","message":"callModuleMethod('blockchain_module','generate_user_config') RPC call failed.","status":"error"}

means the logosctl daemon isn't reachable, or the module isn't loaded. Run logosctl daemon status to tell the cases apart: it reports the daemon state, running or not_running, and the status of each module, loaded, not_loaded, or crashed. Restart the daemon if needed, then load the module:

logosctl daemon start --detach
logosctl module load blockchain_module

logosctl daemon status

If the module shows not_loaded again after a successful load-module, or calls keep failing, check the daemon output for a module crash:

[critical] [logos] [blockchain_module] FATAL: module 'blockchain_module' crashed (signal 4).

signal 4 is an illegal-instruction fault. One known cause: the blockchain module requires a CPU with ADX support. Run grep -c adx /proc/cpuinfo to check. An output of 0 means the CPU, or the CPU model of the VM, lacks ADX. On physical hardware, the module needs an Intel Broadwell or later, or an AMD Zen CPU. On a virtual machine, set the CPU model to pass through host features, for example host in QEMU and Proxmox.

If the count is greater than 0, the crash has a different cause. Collect the complete FATAL lines from the daemon output, including the backtrace addresses, together with the last lines of the newest node log file in the directory where the daemon runs, and report them to the Logos team.

Loaded modules don't persist across daemon restarts, so always re-run load-module after restarting the daemon. A METHOD_FAILED error such as Call to blockchain_module.<method> failed. means the daemon is reachable but the call itself failed. The most common causes are a module that isn't loaded or a missing required argument, such as calling generate_user_config without the JSON initial_peers argument.

My node stays in Bootstrapping for hours and its height stops increasing?​

Check the node log (the <number>.latest file in the directory where you started the daemon). If it repeats failed to process block; cancelling the download err=BlockProcessing(Cryptarchia(FutureBlock { block_slot: ..., current_slot: ... })), the initial block download has stalled. Restart the module; it keeps its state and resumes from the blocks it already stored:

logosctl module unload blockchain_module
logosctl module load blockchain_module
logosctl call blockchain_module start user_config.yaml ""

The start call can return RPC call failed while the node replays its stored blocks. Wait a few minutes, then check get_cryptarchia_info again: height should be increasing towards the network tip.

How do I look up a transaction on the testnet explorer?​

Open https://testnet.blockchain.logos.co/web/explorer/transactions/<TX_HASH>, replacing <TX_HASH> with the transaction hash. The testnet explorer home page has no search box for transaction hashes, and searching by address is not supported.

My wallet balance is not updating after mining?​

If the balance endpoint returns 404 with The requested address could not be found in the wallet, your node hasn't yet synced past the block containing the claim transaction. Funded addresses aren't visible while the node is still Bootstrapping. Wait for the node to reach Online mode and check again. If pow_status shows is_mining as false, run pow_start_mining again: mining stops when the node restarts.
